单位：mm　　

产品编号	Diameter 直 径	Flute Length 刃沟长	Overall Length 全 长	M.T. Number 莫氏圆锥号
23010-1707 1708 1709 1710 1711 1712 1713 1714 1715 1716 1717 1718 1719 1720 1721 1722 1723 1724 1725 1726 1727 1728 1729 1730 1731 1732 1733 1734 1735 1736	53.1 53.2 53.3 53.4 53.5 53.6 53.7 53.8 53.9 54 54.1 54.2 54.3 54.4 54.5 54.6 54.7 54.8 54.9 55 55.1 55.2 55.3 55.4 55.5 55.6 55.7 55.8 55.9 56	230	417	5
23010-1737 1738 1739 1740 1741 1742 1743 1744 1745 1746 1747 1748 1749 1750 1751 1752 1753 1754 1755 1756 1757 1758 1759 1760 1761 1762 1763 1764 1765 1766 1767 1768 1769 1770 1771 1772 1773 1774 1775 1776	56.1 56.2 56.3 56.4 56.5 56.6 56.7 56.8 56.9 57 57.1 57.2 57.3 57.4 57.5 57.6 57.7 57.8 57.9 58 58.1 58.2 58.3 58.4 58.5 58.6 58.7 58.8 58.9 59 59.1 59.2 59.3 59.4 59.5 59.6 59.7 59.8 59.9 60	235	422
23010-1777 1778 1779 1780 1781 1782 1783 1784 1785 1786 1787 1788 1789 1790 1791 1792 1793 1794 1795 1796 1797 1798 1799 1800 1801 1802 1803 1804 1805 1806	60.1 60.2 60.3 60.4 60.5 60.6 60.7 60.8 60.9 61 61.1 61.2 61.3 61.4 61.5 61.6 61.7 61.8 61.9 62 62.1 62.2 62.3 62.4 62.5 62.6 62.7 62.8 62.9 63	240	427
23010-1807 1808 1809 1810 1811 1812 1813 1814 1815 1816 1817 1818 1819 1820 1821 1822 1823 1824 1825 1826 1827 1828 1829 1830	63.1 63.2 63.3 63.4 63.5 63.6 63.7 63.8 63.9 64 64.1 64.2 64.3 64.4 64.5 64.6 64.7 64.8 64.9 65 65.5 66 66.5 67	245	432
23010-1831 1832 1833 1834 1835 1836 1837 1838	67.5 68 68.5 69 69.5 70 70.5 71	250	437
23010-1839 1840 1841 1842 1843 1844 1845 1846	71.5 72 72.5 73 73.5 74 74.5 75	255	442
23010-1847 1848	75.5 76	260	447
23010-1849 1850 1851 1852 1853 1854 1855 1856	76.5 77 77.5 78 78.5 79 79.5 80		514
				6
23010-1857 1858 1859 1860 1861 1862 1863 1864 1865 1866	80.5 81 81.5 82 82.5 83 83.5 84 84.5 85	265	519
23010-1867 1868 1869 1870 1871	86 87 88 89 90	270	524
23010-1872 1873 1874 1875 1876	91 92 93 94 95	275	529
23010-1877 1878 1879 1880 1881	96 97 98 99 100	280	534
